Models
D100M
Lateral expansion joint
without arch
40 to 1,200 mm
standard 150 to 400 mm or
custom face-to-face up to 10 bar up to 200°C low lateral movement capability
custom face-to-face up to 10 bar up to 200°C low lateral movement capability
D110M
Lateral expansion joint
with one arch
20 to 1,200 mm
standard 130 to 350 mm or
custom face-to-face up to 25 bar up to 200°C large lateral and angular movement capability
custom face-to-face up to 25 bar up to 200°C large lateral and angular movement capability
D210M
Lateral expansion joint
with one arch
32 to 500 mm
standard 100 to 110 mm or
custom face-to-face up to 25 bar up to 130°C lateral and angular movement capability
custom face-to-face up to 25 bar up to 130°C lateral and angular movement capability
D123M
Lateral expansion joint
with two arches
100 to 1,200 mm
standard 350 to 650 mm or
custom face-to-face up to 10 bar up to 200°C very large lateral and angular movement capability
custom face-to-face up to 10 bar up to 200°C very large lateral and angular movement capability
We will gladly advise you
Your inquiry to us
Of course, we are also available to you as a contact partner for individual requirements and applications.
This also applies to seemingly impossible cases - whether complex designs, special operating conditions
or extraordinary dimensions. Please contact us.
