Models

U100M

Lateral expansion joint
without arch

Technical data
Contact ditec

80 to 4,000 mm standard 150 to 400 mm or
custom face-to-face
up to 16 bar up to 200°C small lateral movement capability

U100M

80 to 4,000 mm standard 150 to 400 mm or
custom face-to-face
up to 16 bar up to 200°C small lateral movement capability
Technical data


Inquiry

U110M

Lateral expansion joint
with one arch

Technical data
Contact ditec

80 to 4,000 mm standard 200 to 500 mm or
custom face-to-face
up to 100 bar up to 200°C lateral and angular movement capability

U110M

80 to 4,000 mm standard 200 to 500 mm or
custom face-to-face
up to 100 bar up to 200°C lateral and angular movement capability

U216M

Lateral expansion joint
with one arch

Technical data
Contact ditec

100 to 4,000 mm standard 250 to 350 mm or
custom face-to-face
up to 25 bar up to 200°C lateral and angular movement capability

U216M

100 to 4,000 mm standard 250 to 350 mm or
custom face-to-face
up to 25 bar up to 200°C lateral and angular movement capability
Technical data


Inquiry

U120M

Lateral expansion joint
with two arches

Technical data
Contact ditec

80 to 4,000 mm standard 350 to 650 mm or
custom face-to-face
up to 100 bar up to 200°C large lateral and angular movement capability

U120M

80 to 4,000 mm standard 350 to 650 mm or
custom face-to-face
up to 100 bar up to 200°C large lateral and angular movement capability

D100M

Lateral expansion joint
without arch

Technical data
Contact ditec

40 to 1,200 mm standard 150 to 400 mm or
custom face-to-face
up to 10 bar up to 200°C low lateral movement capability

D100M

40 to 1,200 mm standard 150 to 400 mm or
custom face-to-face
up to 10 bar up to 200°C low lateral movement capability

D110M

Lateral expansion joint
with one arch

Technical data
Contact ditec

20 to 1,200 mm standard 130 to 350 mm or
custom face-to-face
up to 25 bar up to 200°C large lateral and angular movement capability

D110M

20 to 1,200 mm standard 130 to 350 mm or
custom face-to-face
up to 25 bar up to 200°C large lateral and angular movement capability

D210M

Lateral expansion joint
with one arch

Technical data
Contact ditec

32 to 500 mm standard 100 to 110 mm or
custom face-to-face
up to 25 bar up to 130°C lateral and angular movement capability

D210M

32 to 500 mm standard 100 to 110 mm or
custom face-to-face
up to 25 bar up to 130°C lateral and angular movement capability

D123M

Lateral expansion joint
with two arches

Technical data
Contact ditec

100 to 1,200 mm standard 350 to 650 mm or
custom face-to-face
up to 10 bar up to 200°C very large lateral and angular movement capability

D123M

100 to 1,200 mm standard 350 to 650 mm or
custom face-to-face
up to 10 bar up to 200°C very large lateral and angular movement capability

We will gladly advise you

Your inquiry to us

Of course, we are also available to you as a contact partner for individual requirements and applications.
This also applies to seemingly impossible cases - whether complex designs, special operating conditions
or extraordinary dimensions. Please contact us.
